- Tool diameter: ø350mm
- Minimum material length: 200mm
- Electrically adjustable rip fence
- Open-frame design
- Manual pressure unit height adjustment
- Maximum depth of cut: 55mm
- Motor power output: 5.5 / 7.5kW
- Feed speed range: 6 – 30 m/min
SPS 300
Photography
Detail
Parameters
- Saw blade diameter: 300 mm
- Maximum depth of cut: 70 mm
- Maximum width of cut: 250 mm
- Tool speed: 3200 rpm
- Main motor power output: 2.2 / 3 / 4 / 5.5 kW
- Machine weight: 300 kg
Description
The KUSING SPS-300 is a fully electric under-table cross-cut saw equipped with a main motor power output range of 2.2, 3, 4, or 5.5 kW. The cutting cycle speed can be continuously adjusted from 2 to 6 seconds via an integrated frequency inverter. The machine features a highly modular concept, offering a wide selection of roller conveyor configurations or variants equipped with NC/CNC controlled positioning stops.
Accessories
SPS 300 2 + 2m
Standard configuration including 2 m infeed and 2 m outfeed conveyors.
Technical Specifications
| Main motor power output | 2.2, 3, 4, 5.5,kW |
| Tool diameter | 300 mm |
| Depth of cut | 70 mm |
| Width of cut | 250 mm |
| Stroke motor power | 0.55kW |
| Spindle speed | 3200 ot/min |
| Cycle speed | 2 – 6 s. |
| Weight | 300 kg |
Scope of Delivery
The machine is supplied with standard conveyor tracks configured according to customer specifications.
